Multispectral imaging
Switch seamlessly between full-color daytime, twilight, and thermal views, with a built-in infrared illuminator for reliable low-light visibility. Scan terrain, detect heat signatures, and identify targets faster for confident, well-informed decisions.
4K Digital full-color sensor
Experience rich, detailed color during the day, clear visibility at twilight, and high-contrast views at night. Built-in infrared ensures reliable low-light performance, letting you scan terrain, identify game, and make informed decisions faster.
Thermal imaging sensors
Reveal subtle heat signatures in any conditions to track movement, spot animals, and interpret behavior with confidence. Choose between premium HD 1280×1024 (DXT50) or highly sensitive 640×480 (DXR50) thermal performance.
Image stabilization
Keep your view steady, even at high magnification. Electronic image stabilization reduces motion blur and compensates for hand movements, letting you track animals, scan terrain, and capture sharp, clear images effortlessly.
Optimized for one-hand use
Operate effortlessly with one hand thanks to dual focusing wheels and intuitively placed controls. Designed for both left- and right-handed use, it keeps adjustments natural and your focus on the action.
Built-in laser rangefinder
Measure distances quickly and accurately up to 1500 m with a powerful laser rangefinder. Switch between scanning and single-shot modes to assess range instantly and plan your next move with confidence.
Combined multispectral PiP modes
View digital and thermal channels simultaneously with picture-in-picture modes, so you can detect, confirm, and track targets confidently, even in complex or low-visibility conditions.
IR Illuminator
Maintain clear visibility in total darkness with a focusable 850 nm infrared illuminator. Three adjustable power levels adapt to changing conditions, ensuring no movement goes unnoticed.
New graphic interface
Navigate settings quickly with an intuitive interface that ensures clear visibility and easy access to key functions. Spend less time adjusting and more time observing, tracking, and making confident decisions in the field.
Other features
- Haptic vibro feedback
- Smart power management
- Classic binocular design
- Photo/video recording with sound
- Tactile 3 position power switch
- True horizontal distance indication
- Stream Vision 2 and Stream Vision Ballistics support
- Integrated ballistic calculator
- 3 sensitivity amplification levels
- Energy saving sleep mode
- 4 digital imaging modes
- USB-C video output
|
Model |
LRF DXR50 |
|
SKU |
77458 |
|
Main Specifications |
|
|
Detection range |
Thermal 2300 m |
|
Sensor |
|
|
Type |
Thermal uncooled, microbolometric Digital 4K CMOS |
|
Resolution, pixels |
Thermal 640x480 / 12 µm Digital 3840x2160 |
|
Sensor NETD, mK |
< 35 |
|
System NETD, mK |
< 18 |
|
Frame rate, Hz |
50 |
|
Optical Characteristics |
|
|
Objective lens |
Thermal F50/1.0 Digital F50/1.8 |
|
Magnification, x |
Thermal 4 – 32x Digital 6.5 – 26x |
|
Field of view (HxV), degrees |
Thermal 8.8° Digital 5.8° |
|
Field of view (HxV), m@100m |
Thermal 15.4 m Digital 10.2 m |
|
Diopter adjustment, D |
-5 / +5 |
|
Interpupillary distance adjustment, mm |
62.5 – 74 |
|
Eye relief, mm |
13 |
|
Infrared Illuminator |
|
|
Emitter |
LED |
|
IR wavelength, nm |
850 |
|
Display |
|
|
Type |
MicroLED (AMOLED) |
|
Resolution, pixels |
1440x1080 |
|
Laser Rangefinder |
|
|
Max. measuring range, m |
1500 |
|
Measurement accuracy, m |
± 1 |
|
Wavelength, nm |
850 |
|
Laser safety class |
Class 1 (IEC 60825-1:2014) |
|
Video Recorder |
|
|
Video / photo resolution, pixels |
1440x1080 |
|
Video / photo format |
.mp4 / .jpg |
|
Built-in memory |
64 GB |
|
Wi-Fi |
|
|
Wireless protocol |
Wi-Fi |
|
Wireless standard |
IEEE 802.11 b/g/n/ac (WPA) |
|
Frequency, GHz |
2.4 / 5 |
|
Environmental Characteristics |
|
|
Degree of protection |
IP67 (waterproof) |
|
Operating temperature range, °C |
-25 – +50 |
|
Connections & Compatibility |
|
|
Mount type |
1/4" socket Tripod adapter with ARCA-SWISS mount support |
|
Supported application |
Stream Vision 2, Stream Vision Ballistics |
|
Weight & Size |
|
|
Body material |
Magnesium alloy |
|
Dimensions, mm |
207 x 132 x 72 |
|
Weight, kg |
1 (battery included) |
