The laser rangefinder is seamlessly integrated into a slim design riflescope. The rangefinder is compact, the receiver and emitter are within clearance limits of a single optical channel. The measuring range is 800 metres – the Thermion 2 LRF provides the hunter with an accurate sense of distance at the hunting site helping to take a precise shot.
High Definition Thermal Sensor
Sharp, richly contrasted thermal imaging for enhanced identification of animals, their extremities and even the smallest details, i.e. branches, leaves, grass and terrain.
Unprecedented Thermal Sensor Sensitivity
Thermal imaging sensor with NETD <25mK ensures perfect detail recognition even in the hardest weather conditions when thermal contrast is low. The smallest temperature differences will be clearly visible during the rainfall, fog or cold mornings in the most difficult conditions for thermal imaging.
Ballistic calculations inside the riflescope
The ballistic calculations for the Thermion 2 LRF are enabled via the new Stream Vision Ballistics mobile application paired with the recent firmware update.
User mode
Use the brightness and contrast adjustments to maximise the detail and informative value of the image in specific observation conditions. The User Mode function saves selected brightness and contrast settings in the device's memory providing optimal image quality for the next use of the thermal imager immediately, with no additional adjustments needed.
Fast Aperture Lens F50/1.0
The characteristics of thermal imaging optics have a decisive influence on a thermal imager’s ability to capture even the lowest radiation levels. Ultimate detection efficiency is achieved with the fast lens of the Thermion 2 LRF (F50/1.0) thermal imager in combination with the highly sensitive thermal sensor. The Thermion 2 LRF gives users the best quality, most detailed & high-contrast, informative imagery every time, even during rain or fog, when the temperature contrast of the observed scene is minimal.
Long detection range up to 2300 m
A powerful long-distance F50/1.0 objective lens combined with a highly-sensitive thermal imaging sensors provides exceptional detection capabilities. A standard 1.8m tall object can be detected on a distances of 1800 ‒ 2300 m away in complete darkness.
Up to 10 hours of battery life on a single charge
The Thermion 2 LRF is powered with two rechargeable batteries: one built-in with a capacity of 4.9 Ah, the other replaceable with a capacity of 2 Ah. A single charge guarantees up to 10 hours of battery life, which covers the time of active use of the scope for a hunt. The embossment on the body of the replaceable battery for accurate determination of the correct position makes it possible to quickly and confidently replace a flat battery with a new one in complete darkness by touch.
High-precision ambidextrous lens focusing
Objective lens with internal focusing mechanism gives a clear and sharp image at any range. Ergonomic focusing wheels are located on the right and left sides, making focusing easy either left- or right-handed.
Photo and video recording
Keep the best moments of observation and share them with your friends and hunting colleagues. One touch of a button is enough to capture an interesting moment or start recording a video. 16 GB of internal memory will give the ability to record many hours of video and tens of thousands of photos.
Stream Vision 2. WiFi integration with iOS and Android devices
The built-in WiFi module will connect the device with smartphones based on Android and iOS via the Stream Vision 2 mobile application. This combination provides a great opportunity, such as wireless update of the device software, transmission of images to the screen of a mobile device in real time, remote control of digital functions of the device and many others. Users registered in the application are provided with cloud storage space for photos and videos taken with a digital or thermal imaging device.
|
Model |
LRF XG50 |
|
SKU |
76554 |
|
Microbolometer |
|
|
Type |
uncooled |
|
Resolution, pixels |
640x480 |
|
Pixel Pitch, µm |
12 |
|
NETD, mK |
< 40 |
|
Frame refresh rate, Hz |
50 |
|
Optical Specifications |
|
|
Lens, mm |
F50 F/1.0 |
|
Magnification, x |
3-24 |
|
Eye relief, mm/inch |
50/1.96 |
|
Field of view (H), °/m@100 |
8,8/15,4 |
|
Diopter adjustment, D |
-3/+5 |
|
Detection distance (Object of "deer" type), m/y |
2300m / 2515 yards |
|
Aiming Reticle |
|
|
Click value, mm@100 m – when magnifying, x |
15 mm – 3х 7.5 mm – 6х 3.75 mm – 12х 1.86 mm – 24х |
|
Click range, mm@100 m (H/V) |
3000H / 3000V |
|
Display |
|
|
Type |
AMOLED |
|
Resolution, pixels |
1024х768 |
|
Operating Features |
|
|
Diameter of the riflescope body to assemble the mounting rings, mm |
30 |
|
Power Supply, V |
3–4.2 |
|
Battery type / Capacity / Rated Output Voltage |
Li-Ion Battery Pack АPS2 / 2000 mAh / DC 3.7 V (removable) or Li-Ion Battery Pack APS3 / 3200 mAh / DC 3.7 V (removable)*
Li-Ion Battery Pack APS5 / 4900 mAh / DC 3.7 V (built-in) |
|
External Power Supply |
5 V, 9 V (USB Type-C Power Delivery) |
|
Battery Packs (built-in APS5 and removable APS2) operating time at temp. = 22 °C, hrs** |
9 |
|
Max. recoil power on rifled weapon, Joules |
6000 |
|
Max. recoil power on smoothbore weapon, caliber |
12 |
|
Degree of protection IP code (IEC60529) |
IPX7 |
|
Operating temperature, °С / °F |
-25 – +50 / -13 – +122 |
|
Dimensions with an eyecup, mm/inch |
420x78.5x94.5 / 16.54x3.09x3.72 |
|
Weight (without removable battery), kg/oz |
0.97 / 34.22 |
|
Video Recorder |
|
|
Photo / video resolution, pixels |
1024x768 |
|
Video / photo format |
.mp4 / .jpg |
|
Built-in memory |
16 GB |
|
Wi-Fi Channel*** |
|
|
Frequency |
2.4/5 GHz |
|
Standard |
IEEE 802.11 b/g/n/ac |
|
Laser Rangefinder |
|
|
Wavelength, nm |
905 |
|
Max. Measurement Range, m/y**** |
800m / 874.9 yards |
|
Measurement Accuracy, m |
1 |
* Purchased separately.
** The actual operating time depends on the intensity of using Wi-Fi, video recorder, laser rangefinder.
*** The reception range may vary depending on various factors: obstacles, other Wi-Fi networks.
**** Depends on the characteristics of the object under observation and environmental conditions.
